DT Dynamic 1
DT 1-Way Masking screens feature a top mask only allowing cost effective masking solutions where more complex masking is not required. These screens also feature a minimal frame size enabling the maximizing of the projected image size in a smaller room.
How we specify a Houston theater
Dedicated theaters in Houston usually start with a light-controlled room and a screen in the 1.0 to 1.3 gain range. We work the projector choice backwards from seating distance and screen width, then set the audio for multiple rows instead of a single sweet spot. For the DT Dynamic 1 specifically, we confirm the fit against your room in Houston, TX before quoting the install.
Service area: Houston, Memorial, River Oaks, Bellaire, West University Place, The Woodlands, Katy, Sugar Land.
Specifications
Screen
| Size | Constant Width, Variable Height masking; Width = Viewable Screen width + 5" (127mm); Height = Viewable Screen height + 5" (127mm); Max frame depth = 5" (127mm); Wall Surface to image Surface = 2.68" (68mm) |
|---|---|
| Aspect Ratios | Top masking for 2 preset aspect Ratios |
| Color | Black Velvet |
| Installation | Adjustment | Front image surface fitting - fit the frame to the wall then install the image surface |
| Motor | Whispertec quiet motor |
| Power Type | 120v or 230v |
Available Materials
| Slate AT 1.2 | Gain 1.2; ALR 65; Acoustic Yes |
|---|---|
| ATRef | Gain 0.8; ALR 10; Acoustic Yes |
| ATProV2 | Gain 0.7; ALR 10; Acoustic Yes |
Features
- The Dynamic 1 features 1-way motorized top masking supporting a choice of two aspect ratios, for example 1.78 and 2.4. This constant width and variable height masking perfectly frames most TV and movie content.
- The basic motor control system enables easy interface to a control system and movement of the mask between two defined positions.
- The proprietary Whispertec motor system runs at just 30dB which makes the Dynamic 1 the quietest masking screen in operation.
Documents
Related models
Want this model specified for your room?
Send us the room size, seating distance and what you watch. We will confirm the right model and screen for Houston, TX, then quote the install.
